GRAND HARBOR® COLLECTION

Grand Harbor Collection 1

GRAND HARBOR® COLLECTION

Steel and composite carriage house garage doors with or without insulation.

Grand Harbor Collection 2Grand Harbor Collection 3

When budget is the deciding factor, this low-maintenance, insulation-optional steel frame carriage house style garage door combines clean lines and classic charm to provide a popular style at a great value.

DESIGN YOUR GARAGE DOOR

OVERVIEW

A great choice for both new construction or  a low-maintenance replacement, the GRAND HARBOR® collection of garage doors is a versatile carriage house design that complements a wide range of architectural styles.

CONSTRUCTION OVERVIEW

  • Smooth composite overlays are adhered to a flush 24-gauge steel door, with 2- or 1-layer carriage house construction.
  • Optional 1-5/8″ vinyl-backed polystyrene insulation improves energy efficiency. Insulated doors have a 6.3 R-value.
  • The steel skins of these doors are protected by the use of a tough, layered coating system, which includes a hot-dipped galvanized layer and baked-on primer and top coat.
  • WINDCODE® reinforcement product available for high wind load applications. (Click for details)

DESIGN OVERVIEW

  • Four factory finish paint colors.
  • Clear, obscure, and acrylic glass options available.
  • Attractive beveled edge clip-in window grilles are removable for easy cleaning.
  • Garage doors come complete with spade lift handles and step plates. Additional decorative hardware options available.

Calculated door section R-value is in accordance with DASMA TDS-163.

Grand Harbor Collection 4Grand Harbor Collection 5Grand Harbor Collection 6Grand Harbor Collection 7

Grand Harbor Collection 8LIFTMASTER® ELITE SERIES™
Clopay recommends the LiftMaster® Elite Series opener for these garage doors.

DOOR DESIGNS

SERIES 1

Grand Harbor Collection 9 Grand Harbor Collection 10 Grand Harbor Collection 11
DESIGN11 DESIGN12 DESIGN13

SERIES 2

Grand Harbor Collection 12 Grand Harbor Collection 13
DESIGN21 DESIGN22

SERIES 3

Grand Harbor Collection 14 Grand Harbor Collection 15
DESIGN31 DESIGN36

SERIES 4

Grand Harbor Collection 16
DESIGN41

TOP SECTIONS

SOLID TOP SECTIONS – SERIES 1 & SERIES 2

Grand Harbor Collection 17 Grand Harbor Collection 18 Grand Harbor Collection 19
TOP11 TOP12 TOP13
Grand Harbor Collection 20
ARCH1

SOLID TOP SECTIONS – SERIES 3 & SERIES 4

Grand Harbor Collection 21 Grand Harbor Collection 22
TOP11 ARCH1

WINDOW DESIGNS

Grand Harbor Collection 23 Grand Harbor Collection 24 Grand Harbor Collection 25
PLAIN SHORT SQ22 – GH PLAIN LONG
Grand Harbor Collection 26 Grand Harbor Collection 27 Grand Harbor Collection 28
REC12 REC14 SQ24
Grand Harbor Collection 29 Grand Harbor Collection 30 Grand Harbor Collection 31
ARCH1 GRVA1 GRLA1
Grand Harbor Collection 32 Grand Harbor Collection 33 Grand Harbor Collection 34
XA24* XG14* XG24*
Grand Harbor Collection 35 Grand Harbor Collection 36
WROUGHT IRON SHORT WROUGHT IRON LONG

DOUBLE TOP SECTIONS

Grand Harbor Collection 37 Grand Harbor Collection 38
ARCH3 – SOLID (DOUBLE DOOR) ARCH3 – WINDOW (DOUBLE DOOR)
 Grand Harbor Collection 39  Grand Harbor Collection 40
GRLA3 – WINDOW (DOUBLE DOOR) GRLA3 – WINDOW (DOUBLE DOOR)
Grand Harbor Collection 41 Grand Harbor Collection 42
XA314 – WINDOW (DOUBLE DOOR) XA324 – WINDOW (DOUBLE DOOR)

*Faux windows.

COLORS

Grand Harbor Collection 43 Grand Harbor Collection 44 Grand Harbor Collection 45 Grand Harbor Collection 46
STANDARD WHITE ALMOND DESERT TAN SANDTONE

*Available on select models.
Color Blast Custom Paint Option Available.

HARDWARE DESIGNS

CLAVOS

Grand Harbor Collection 47 Grand Harbor Collection 48
DIAMOND CLAVOS ROUND CLAVOS

HANDLES

Grand Harbor Collection 49 Grand Harbor Collection 50 Grand Harbor Collection 51
SPADE LIFT HANDLES (STANDARD) ESCUTCHEON PLATE(S) TWISTED “T” HANDLE

HINGES

Grand Harbor Collection 52
SPADE STRAP HINGE

PLATES

Grand Harbor Collection 53
SPADE STEP PLATE (STANDARD)
  1. Grand Harbor Collection 54Smooth composite overlay
  2. Steel
  3. 1 5/8″ polystyrene insulation (optional)
  • Replaceable vinyl bottom weather seal in rust free aluminum retainer helps protect against the elements.
  • Grilles are removable for easy cleaning.
  • Patented Safe-T-Bracket® – Prevents serious injury that could occur if the bottom bracket were removed with the garage door closed and under tension.
  • Rust-Prevention System – Steel skins are protected through a tough, layered coating system, including a hot-dipped galvanized layer, a protective metal oxide pretreatment and a baked on primer and top coat.
Grand Harbor Collection 55 Grand Harbor Collection 56
Safe T-Bracket® Rust-Prevention System

Door sample is shown in white.
